The innovative, modular, weld-free frame construction of this series product ensures them the maximum fatigue resistance, optimum reliability and a variety of mounting options. Combined with high-quality cast steel components and first-class spherical rolling bearings, the high productivity, high efficiency and low cost of the crushing operation are fully guaranteed. No matter what your crushing needs are, from hard, strong abrasive rock to a variety of other recycled materials, you can find the best solution from the PEC jaw crusher.

Product advantages
• Modular, weld-free frame structure
• Durable jaw assembly
• Integral cast steel bearing housing
• Repairable crusher rack

Specifications


		PEC80	PEC96	PEC110	PEC106	PEC116	PEC3054	PEC110	PEC125	PEC140	PEC145	PEC160	PEC200
Feed port width（mm）		800	930	1000	1060	1150	1375	1100	1250	1400	1400	1600	2000
Feed port depth（mm）		510	580	760	700	800	760	850	950	1070	1100	1200	1500
Power（kw）		75	90	110	110	132	160	160	160	200	200		400
Speed（rpm）		350	330	260	280	260	260	230	220	220	220	220	200
Size （mm）	Discharge opening （mm）	t/h	t/h	t/h	t/h	t/h	t/h	t/h	t/h	t/h	t/h	t/h	t/h
0-30	20
0-35	25
0-45	30
0-60	40	65-85
0-75	50	80-95
0-90	60	95-125	120-155
0-105	70	115-150	140-180	150-210	155-200	170-220	240-310	190-250
0-120	80	130-170	160-210	170-225	175-230	190-250	270-350	210-275
0-135	90	150-195	180-235	190-245	200-260	215-280	295-385	235-305
0-150	100	165-215	200-260	215-280	220-290	240-310	325-425	255-330	290-380
0-185	125	210-275	250-325	265-345	280-365	295-385	390-510	310-405	350-455	385-500	400-520
0-225	150	250-325	300-390	315-410	335-435	350-455	460-600	370-480	410-535	455-590	470-610	520-675
0-260	175	290-380	350-455	370-480	390-510	105-525	530-690	425-550	470-610	520-675	540-700	595-775	760-990
0-300	200			420-540	445-580	160-600	600-780	480-625	530-690	590-765	610-795	675-880	855-1110
0-340	225								590-770	655-850	680-885	750-975	945-1230
0-375	250								650-845	725-945	750-975	825-1070	1040-1350
0-410	275										820-1070	900-1170	1130-1470
0-450	300											980-1275	1225-1590

NOTE: The specifications above are for reference only; for more configurations, please consult our sales staff.
